C-series
C-Series
- No Access Level Limits
- True 2 Doors / 4 Readers Capability
- High Capacity
- Multispeed Serial RS485 Link
FeaturesConfiguration DiagramDocumentation
| No | Item | Features | |
| XP-C2000 | XP-C2000N | ||
| 1. | No. of Doors |
2 Doors
|
|
| 2. | No. of Readers |
Max 4 Readers (Plato Readers) – 2 Entry / 2 Exit
|
|
| 3. | Wiegang / ABA Reader |
Yes – Max 2
|
|
| 4. | Connection to PC |
RS485 (19,200bps)
|
RS485 (19,200bps)
/ IP (100baseT) |
| 5. | Connection to Reader |
1. RS485 – Plato Reader Series
2. Wiegand / ABA |
|
| 6. | Card Holders |
5,000 (16 Digits)
|
|
| 7. | Transactions |
10,000
|
|
| 8. | Time Setting |
255 Time Sets / 255 Time Zone
|
|
| 9. | Access Level |
No Limits
|
|
| 10. | Holiday |
30 (2 sets)
|
|
| 11. | Inputs |
7 (Digital)
2 Door Sensors + 2 Exit Buttons 1 Dedicated Fire Alarm Input 2 Configurable as Reader Tamper, Emergency Breakglass Monitor or General Purpose |
|
| 12. | Door Relay Output(s) |
Yes (2)
|
|
| 13. | Real Time Clock |
Yes – with On Board Battery
|
|
| 14. | Power Fail Monitor |
Yes – with Power Level Monitoring
|
|
| 15. | Firmware Upgrade |
Download from Software
|
|
| 16. | Onboard LED Indicators |
Yes – Input, Output, Run, Diagnostic, Error
|
|
| 17. | Onboard Buzzer |
Yes
|
|
| 18. | Enhanced Over Voltage Protection |
Yes
|
|
| 19. | Use with Other MicroEngine controllers |
Yes
|
|
| 20. | Power |
240VAC
|
|
| 21. | Dimension |
295mm (H) x 285mm (W) x 80mm (D)
|
|
| No | Documentation |
| 1. |  Product Brochure: C-Series |
